CCR1009-7G-1C-1S+

TECHNICAL SPECIFICATIONS

• Processor: 9 core CPU TLR4-00980 1.2GHz (each core), 2GB DDR3 RAM, 128MB Flash, TILE architecture, RouterOS L6
• Network communication ports: 7×10/100/1000Mbps RJ45, 1xCombo 1000Mbps RJ45/SFP, 1xSFP+ 10Gbps
• MicroUSB port: 1 (Memory USB/ 3G/ LTE…)
• Serial port: 1 (RS232 + Header)
• MicroSD slot: 1
• PoE in/out support: 1xPoE in
• Network performance (routing fast path): 15.398Gbps (packets 512 bytes or larger), 17.411Mpps (64-byte packets)
• Maximum power consumption: 39W
• Operating Temperature: -20°C ~ 60°C
• Concurrent Users (Recommended): 4000~5000 Connections
• Power Supply: 2xAC, 100-240VAC, 50/60Hz or Passive PoE
