GWN7600LR

SPECIFICATIONS

• Device type: Outdoor
• Wifi standard: 802.11 a/b/g/n/ac (Wave-2)
• Operating frequency range: 2.4GHz and 5GHz
• Maximum data rate: 1267Mbps (400Mbps/2.4GHz and 867Mbps/5GHz)
• Communication network port: 2×10/100/1000 Base-T Ethernet Ports, RJ45
• Support number of broadcast names: 16 SSID/radio
• VLAN support: 802.1Q, VLAN per SSID
• Transmission power: Very strong, 26dBm (398mW)/ 2.4GHz, 26dBm (398mW)/ 5Ghz
• Coverage: Very wide, up to 300m
• Security: WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
• Antenna: Integrated/ omnidirectional, 4dBi, 2×2:2 2.4GHz (MIMO); 5dBi, 2×2:2 5GHz (MU-MIMO)
• Wireless Mode: Access Point, Station, Mesh
• Network Mode: NAT, Bridge, Hotspot (UAM)
• Maximum power consumption: 23.0W
• Operating temperature: -30°C ~ 60°C
• Concurrent users (recommended): 100 connections
• Power supply: PoE 802.3at/af or DC: 24V 1A
